Technical Specification

Principals: ALT, AST, ALP, GCT, TP, Alb, TBIL, DBL,

LDH, CK, CK-MB, a-HBDH, CHO, TG,

HDL C, LDL_C, Apo Al, Apo B, Lp(a),

BUN, CRE, I-JA, C02-CP, AMS, LIP, CLU, HbAIC, lgA, lgG, lgM, C3, C4, CRP, Alcohol etc.

Test Method: Endpoint , Fixed-time , Kinetics and Turbidimetry

Light source: Halogen lamp, 6V IOW Auto sleeping function

Wavelength: 7 standard wavelengths: 340nm, 405nm,

450nm, 510m, 546nm, 578nm, 630nm; optional: 670nm

Photometric Range: 0-3.2 ABS

Accuracy: 0.0001A

Flowcell: Quartz glass flow cell

Capacity & optical path: 32ul, 10mm

Input: 7.0" T FT LCD Touch screen with touch pen Mouse or keyboard via USB

Temperature control: Peltier cooling system Room temperature, 25 0 C, 30 0 C, 37 0 C.

Printer: Built-in thermal printer, Support external printer (HP series,

PCL6 series printers)

Interface: Network Portxl, for supporting data transmission, USB port (2. 0) x2: for keyboard , mouse or external printer

Working environment: Temperature : 10⁰ C-30⁰ C Humidity : 30 %-80 %

Power: Wide power supply : AC 100-240V, 50 /

60Hz

Dimension: 354*292*150mm

Storage: More than 100,000 test results

Weight:5.2kg
