General Information

Throughput

Up to 200 tests/hour

Measurement Principle

Micron superparamagnetic particles platform + ALP

Sample System

Sample Feeder

Continuous sample loading and unloading

Test Mode

Random, batch, STAT mode

Sample Position

50

STAT Position

1 independent emergency sample position

Sample/Reagent Probe

1 Steel probe, has the functions of probe blockage detection, liquid level detection, volume tracking and 3D collision protection

Sample Volume

5-100μL, with increment of 1μL

Sample Type

Serum, plasma, urine

Sample Tube

Micro cuvettes and original blood sampling tube

Reagent System

Reagent Position

20

Cooling System

2~8°C, 24h cooling

Reagent Pack

50 tests/kit, 100 tests/kit

Reagent Scanning

Built-in/External bar code reader

Reagent Volume

20-150μL, with increment of 1μL

Substrate Loading

Capable of continuous loading during testing

Substrate Heating

Constant heating

Incubation Temperature

37°C±0.3°C

Incubation Positions

100

Separation System

3-phrase magnetic separation

Measurement and Reaction System

Detection Mode

Photon counting

Signal Detector

PMT photon counter

Temperature

37°C±0.3°C

Mixing Unit

Non-touch vortex mixing

Operation System
